Basketball Stadium Perimeter LED Display P8 Outdoor LED Banner
Quick Details:
1, Pixel Pitch: 8mm.
2, Refresh rate: 1,920Hz.
3, SMD, viewing angle: 160°/ 160°.
4, Meanwell driver, 3years warranty.
5, Aluminium cabinet, stadium, rental dual usage.
6, Standard cabinet size: 960×960x150mm, customized cabinet:
1280x960mm or 1920x960mm.
Description:
TBC Stadium Perimeter LED Displays include outdoor led screen: 8mm,
10mm, 12mm and indoor led perimeter: 6mm and 10mm.
Application:
TBC Stadium Perimeter LED Screens are widely used for brand logo
message advertising, live broadcasting in basketball, soccer,
football, baseball stadium.
Features and Advantages:
1, Convenient connections enable easy and fast installation.
2, TPE material soft mask, to protect the player and screen.
3, Adjustable cabinet inclining angle, for best viewing and camera
shooting.
4, Automatic back-up data system for non-stop displaying.
5, 160°/160° wide viewing angle for audiances from different
directions.
6, High refresh rate, no strip for camera live broadcasting.
7, Good waterproof protection: front IP65, rear IP54, no problem
for outdoor application.
8, Meet FIFA safety standard.
Parameters:
| Parameter | Unit | Value |
| Brightness | nits | 6000 |
| Color temperature | deg.k | 3200 ~ 9300 |
| Viewing angle - Horizontal | deg. | 160(+80/-80) |
| Viewing angle - Vertical | deg. | 160(+80/-80) |
| Cabinet weight | kg | 50 |
| Cabinet width | mm | 960 |
| Cabinet height | mm | 960 |
| Cabinet depth | mm | 150 |
| Cabinet area | sq. m. | 0.92 |
| Cabinet material | | Cold Steel |
| Aspect ratio | | 4:3 |
| Ingress protection (Front/Rear) | IP | IP65/IP54 |
| Operating temperature range | deg. C | - 20 to 50 |
| Operating humidity range | HR | 10％ to 90％ |
| Pixel type and configuration | R/G/B | SMD 3in1 |
| Pixel pitch | mm | 8 |
| Pixel matrix per cabinet | | 120x120 |
| Pixels per cabinet | | 14400 |
| Lines per meter | | 125 |
| Pixels per sq. meter | | 15625 |
| LEDs per sq. meter | | 15625 |
| Recommended minimum viewing distance | m | 8 |
| Colours | | 281trillion |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Digital processing | bit | 16 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 1920 |
| Input voltage | VAC | 110/240 |
| Input power frequency | Hertz | 50/60 |
| Input power (max/avg) | Watts per sq.m | 850/290 |
| MTBF | Hours | ≥10000 |
| Lifetime (50%Brightness) | Hours | ≥100000 |
| Module brightness uniformity | | ＜5％ |
| Blind spot rate | | ＜0.0001 |
| Earth leakage current | mA | ＜2 |
| Red wavelength | nm | 623 |
| Green wavelength | nm | 525 |
| Blue wavelength | nm | 470 |
| Panel input format (with video processor) | | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV |
| Data interconnection | | CAT6 cable/Fiber |
| Operating system | | Windows(XP/Vista/7/8/10) |
| Control distance | | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. |
