Features
1. Ultra-Thin
Screen weight is light, no pressure on the glass, thickness about
4mm, weight 3-6kg/ sqm
2. Transparent
The structure is extremely simple, high permeability,
does not affect the glass curtain wall lighting, permeability up to
85%
3, Easy to install
directly attached to the glass surface, and then the signal, power
can be connected
4. Save costs
Product installation does not require additional steel frame
structure,
does not need to change the appearance of the auxiliary building,
effectively reduce transportation and installation costs
5.Large viewing Angle
Up and down left and right field of view up to 140 degrees, viewing
without dead corners,
no color bias, the image is always perfect and seamless
Applications
Retail display: Transparent LED screens provide striking images. It is ideal for
displaying products in stores and other retail outlets. Retailers
can create truly engaging shopping experiences. They do this by
combining visual effects with physical objects.
Art installation: Transparent LED screen offers endless possibilities for creative
art display. These screens allow artists to explore new avenues of
expression. It could be an interactive light show or a futuristic
mural.
Advertising: Companies can use transparent LED screens to stand out from the
competition. In addition, they also draw attention to their brand
or product. These types of displays are ideal for major events or
areas with high foot traffic.
Corporate events: Transparent LED screens help create an impressive atmosphere for
corporate events. It can display relevant content, such as a
company logo, messages, or videos. This adds a sense of
professionalism and makes any event more memorable and exciting.
Trade shows: Trade shows are the perfect opportunity to showcase new products
or services with the help of transparent LED screens. They can also
create amazing backdrops for presentations and group discussions.
Outdoor billboard: The LED transparent screen has higher brightness and wider
viewing Angle, and can be clearly visible even in direct sunlight,
which is very suitable for outdoor use. They are made of glass,
durable and can withstand harsh weather conditions.
Architectural glass curtain wall: The LED transparent screen can be applied to the glass curtain
wall of the building. It creates a striking display that blends
seamlessly with the exterior design. Because of their transparency,
these screens do not block views of the building's interior or
exterior. This makes them an attractive addition to any project.
Airports: Transparent LED screens provide a modern and sophisticated look
in terms of visibility and security. The screens can display gate
information, flight delays and even advertisements. They are also
perfect for providing direction to travelers. It can be programmed
to display different languages. Therefore, the LED transparent
screen also has the characteristics of energy saving and
durability, which is the only choice for busy airports.
Parameters
Project | Unit | parameter | parameter | parameter | parameter |
Product No |
| DM4/8 | DM6.5 | D10 | D20 |
light source model | SMD | 2121 | 2121 | 2121 | 2121 |
Density | dot/m2 | 31250 | 23668 | 10000 | 2500 |
Module Size | mm | 960(H)X256(W) | 962(H)X208(W) | 960(H)X320(W) | 960(H)X320(W) |
Screen compositon | High transparency,high temperature resistance,flame retardantPC |
Weight | kg/m2 | 6 | 6 | 6 | 6 |
Permeability |
|
|
|
|
|
Brightness | cd/m2 | ≥4000 | ≥5000 | ≥5000 | ≥3000 |
Refresh | Hz |
|
|
|
|
Scan |
| stati | stati | stati | stati |
Maximum power | W/m2 |
|
|
|
|
average power | W/m2 | 300 | 300 | 200 | 200 |
installation method |
|
|
|
|
|
maintenance method |
Pre/Post Maintenance |
Brightness Level |
| 256 |
| Operating Voltage | | DC5V |
gray scale | bit | 12- 16 |
IP | IP | IP30 |
Viewing angle | Degree | Horizontal≥150度, Vertical ≥ 150 |
Input voltage |
| degreesAC95V~240V |
Operating temperature | °C | -20~65 |
Working humidity |
| 10% ~90RH |
service life | 1 00000 hours |
