P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm

Topbright Creation Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm from wholesalers

    Buy cheap P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm from wholesalers
    • Buy cheap P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm from wholesalers
    • Buy cheap P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm from wholesalers
    • Buy cheap P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm from wholesalers

    P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm

    Ask Lasest Price
    Brand Name : TBC LED
    Model Number : P2.5
    Certification : FCC, CE, ROHS
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 sqm per month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm

    SMD2121 HD 4K LED Video Wall With Die Cast Aluminum Cabinet 640x480mm


    P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm


    Application Of LED Video Wall

    Indoor stores often use LED splicing display screens for information display and business promotion. For example, indoor stores such as postal services, mobile telecommunications, and brand stores use LED displays to display product information, promotional activities, and other content, attracting customers to come into the store for consumption. At the same time, LED splicing display screens can also beautify the store image and enhance brand image.
    The lobby of hotels or resorts is also one of the application scenarios for LED splicing display screens. Install LED display screens in the lobby to display diverse content such as hotel or resort introductions and service information, enhancing the guest's stay experience. Meanwhile, LED display screens can also serve as one of the decorations in the lobby, enhancing the level and image of hotels or resorts.
    Performances or gatherings are also one of the important application scenarios for LED splicing display screens. At performances or gatherings, LED display screens can serve as stage backgrounds, enrich stage scenes, and provide audiences with a more immersive viewing experience. At the same time, LED displays can also enhance the atmosphere, allowing people to experience an unforgettable audio-visual feast.
    Building curtain walls are also one of the application scenarios for LED display screens. LED display screens and building curtain walls are often used in bustling urban areas, not only for energy-saving lighting, but also for promoting and transmitting information. By installing LED display screens on building curtain walls, urban culture, commercial advertisements, and other content can be displayed, enhancing the image and visibility of the city.
    In summary, the application fields of LED splicing display screens have become increasingly widespread, involving more and more scenarios. With the development of technology and the growth of market demand, the market size of LED splicing display screens is also expected to further expand. In the future, with the continuous innovation of technology and the expansion of application scenarios, LED splicing display screens will be applied and developed in more fields.


    Quick detail Of Indoor Fixed LED Video Screen

    1, Pixel Pitch: 2.5mm, 3mm, 4mm
    2, Nation Star or Kinglight SMD LEDs, high contrast and high reliability
    3, Greyscale: 16bits
    4, Cabinet size: 768x768mm or 960x960mm Steel Wall Mount Cabinet
    5, Service type: Magnetic front service

    6, PSU: MEANWELL or G energy brand

    7, Refresh Rate: 1920-3840Hz

    8, Ingress Rate: IP43 indoor use and magnetic front service

    9, Quality Certificate:CE, RoHS,FCC, ETL

    10, Brightness:>800-1000cd/sqm


    Specification Of Indoor Fixed LED Screen

    E 2.5E 3E 4
    Pixel Pitch2.5mm3mm4mm
    Pixel ConfigurationSMD2121SMD2121SMD2121
    Pixel Density160,000 pixels/m2111,111 pixels/m262,500 pixels/m2
    Module Dimensions(W x H) (mm)320 x 160192 x 192256 x 128
    Panel Dimensions (mm)

    960 x 960 x 100

    640 x 480 x 100

    960 x 960 x 100


    1024 x 1024 x 100


    Module Resolution168 x 8464 x 6464 x 32
    Cabinet Resolution384 x 384320 x 320256 x 256
    Panel MaterialSteelSteelSteel
    Weight per Cabinet26kg26kg26kg
    Digital Processing16bit16bit16bit
    Colours281 trillion281 trillion281 trillion
    Contrast Ratio5,000 : 15,000 : 15,000 : 1
    Average Power Consumption200 W /Sqm200 W /panel200 W /panel
    Max Power Consumption650 W /Sqm650 W /panel650 W /panel
    Brightness>8,00 nits>8,00 nits>8,00 nits
    Refresh Rate>3,840Hz>3,840 Hz>3,840 Hz
    Vertical Viewing Angle160°160°160°
    Horizontal Viewing Angle140°140°140°
    Expected Lifetime100,000 Hrs100,000 Hrs100,000 Hrs
    ServicingFrontFrontFront
    IP Rating (Front/Rear)IP 43IP 43IP 43
    Operating Temp/Humidity-20ºC - 50ºC / 10% - 90%-20ºC - 50ºC / 10% - 90%-20ºC - 50ºC / 10% - 90%
    Storage Temp/Humidity-20ºC - 50ºC / 10% - 90%-20ºC - 50ºC / 10% - 90%-20ºC - 50ºC / 10% - 90%
    Scan Method1/21 Scan1/16 Scan1/13 Scan

    Description Of Indoor Fixed LED Screen

    TBC LED E Series indoor fixed led screen include P2.5mm, 3mm and P4mm Features are:

    1, Die-cast aluminum wall mount cabinet, can be installed to the wall directly

    2, High refresh rate 3840Hz adjustable

    3, Magnetic modules, Front and Rear Maintenance via Magnets

    4, NOVA Star or Colorlight system free to choose

    5, Easy to use and installation

    indoor led video wall


    P2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mmP2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mmP2.5mm Indoor HD 4K LED Video Wall with Die Cast Aluminum Cabinet 640x480mm


    Our Services


    1. 10 Years professional led display manufacturer

    2. Short delivery time: 5-15 working days, adjustable according to customer request
    3. Wholesale price

    4. OEM and ODM service
    5. Customizable product upon request


    FAQ


    How to deal with the phenomenon of LED screen distortion?


    1, reconnect the communication line, carefully check the LED display wiring instructions, and then carefully connect according to the instructions above, the interface should be plugged tightly, to avoid short circuit or poor contact and other phenomena.

    2, use a multimeter to detect the internal connection line of the LED display, find out the poor contact or short circuit line, and replace the high-quality circuit connection line.

    3, use a multimeter to detect whether the power supply of the LED display is grounded, the screen flower may also be caused by this reason, if there is a problem, the power grounding can be.

    4, if the above methods can not solve the problem, it may be the LED lamp beads or screen is broken, it is recommended to contact the manufacturer as soon as possible to repair, so as not to further deteriorate the bad point.

    led display aging test needs to pay attention to the following issues:

    1. Test content: white screen, red, green, blue monochrome, gray gradient, video effect, text effect.

    2, the test time of led display playing white screen is not less than 24 hours.

    3, monochrome and gray gradient test not less than 24 hours.

    4, video and text effect test not less than 24 hours.

    5, LED display aging test must be on duty, find problems in time to report to the engineering manager.
