5000nits Stage Rental LED Display
5000nits P4.81mm Outdoor Rental LED Screen With 3840Hz Refresh Rate
Outdoor P4.81mm 500x500mm Die Cast Aluminum Cabinet High Brightness
5000nits With 3840Hz Refresh Rate
Feature Of Outdoor Rental LED Screen
In today's era, LED rental screen has been the standard for the
stage, vivid image of the wonderful performance with a realistic
background switch, both shocking and stunning, is the stage
interpretation of the good partner, 10,000 people share the
excitement, there should be enough professional display screen, the
pursuit of stage interpretation display, is also being recognized
by many customers such a larger and more professional stage.
1, TBC LED P4.81 LED rental screen, refresh frequency of 1920Hz or
more, clear and delicate picture, color realistic, stable
performance, excellent display effect, giving a kind of immersive
scene experience;.
2, The use of standardized box structure, a cast into the shape,
high flatness; easy to disassemble, light quality, convenient
transportation. The lightness of the box, can be quickly installed,
dismantled and transported, infinite compatibility, to meet the
requirements of lifting, stacking and so on.
3, The use of synchronous control of the system processing, can
accept DVI, VGA, HDMI, S-video, composite, YUV and other kinds of
video input signal, can play video, graphics and other programs at
will, to real-time, synchronous, clear information dissemination of
various kinds of information.
4, high strength hardness precision, good heat dissipation, low
power consumption of the box, energy saving and environmental
protection.
This is one of the star products carefully built by TBC LED for the
indoor and outdoor rental market, and its powerful visual impact
and excellent advertising ability have been widely used in
exhibitions, performances and other commercial display occasions.
Especially in recent years, with the national policy to vigorously
support the development of cultural and tourism industries around
the country, China's culture, entertainment and sports industry
vitality further release, LED display rental market has huge
potential and strong market demand.
Quick detail Of Outdoor Rental LED Screen
1, Pixel Pitch: 2.9mm, 3.91mm, 4.81mm
2, Waterproof Nation Star SMD LEDs, high brightness and high
reliability
3, Greyscale: 14bits with NOVA MRV328
4, Cabinet size: 500x500mm and 500x1000mm Die Cast Aluminum Cabinet
5, Service type: Rear service for smooth surface
6, PSU: Brand power supply, stable and reliable
7, Refresh Rate: 1920-3840Hz
8, Ingress Rate: IP68 Outdoor standard
9, Quality Certificate:CE, RoHS,FCC, ETL
10, Brightness:>5000cd/sqm
11, Curve Installation: Rotary lock for +- 15 degree Concave and
Convex shape
12, Corner Protector: Optional
Specification Of Outdoor Rental LED Screen
| XT 2.9 | XT 3.9 | XT 4.8 |
| Pixel Pitch | 2.976mm | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 86,016 pixels/m2 | 65,536 pixels/m2 | 43,264 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 500 x 1000 x 80 | 500 x 500 x 80 500 x 1000 x 80 | 500 x 500 x 80 500 x 1000 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 | 2 x 2 | 2 x 2 |
| Module Resolution | 84 x 84 | 64 x 64 | 52 x 52 |
| Cabinet Resolution | 168 x 168 | 128 x 128 | 104 x 104 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg | 7.5kg | 7.5kg |
| Digital Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm | 200 W /panel | 200 W /panel |
| Max Power Consumption | 650 W /Sqm | 650 W /panel | 650 W /panel |
| Brightness | >5,000 nits | >5,000 nits | >5,000 nits |
| Refresh Rate | >3,840Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front |
| IP Rating (Front/Rear) | IP 68 | IP 68 | IP 68 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/21 Scan | 1/16 Scan | 1/13 Scan |
Description Of Outdoor Rental LED Screen
TBC LED outdoor rental led screen include P2.9mm, 3.91mm and
P4.81mm Features are:
1, Adjustable Angle lock for curve Application via Rotary Lock
2, Advanced Flash Function: The Calibration Data can be Saved to
the receiver card and used automatically
3, Outdoor Waterproof IP68 Standard, Front and Rear Maintenance via
Magnets
4, Rubber seal for the back of module, to create maxiumum
protection against rain or moisture
5, Easy to use corner protectors, push it and corner protector
released
Application Of Outdoor LED Video Wall
1. Ultra-light - weight only 8kg, one hand can be carried, quick
installation
2. Ultra-thin - the box body is made of die-casting aluminum
molding, high strength, toughness, high precision, not easy to
deformation, for the transportation of labor-saving
3. High precision - size is electromechanical processing accurate
to 0.1mm
4. Compatible - new structure design, to meet the requirements of
lifting, stacking, to meet the requirements of indoor and outdoor
5. Quick - box up and down left and right connection using fast
locking mechanism
6. Reliable - high strength and hardness, good heat dissipation
7. Cost - light weight of the box, the required installation costs
are low; low power consumption of the box, saving operating costs
and reducing labor costs
Our Services
1. 10 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
FAQ
Q1. How does the semi auto corner protector work?
A: Gently push the button, the corner protector will release and
cover the corner area.
Q2. What installation options do we have?
A: Either stacking on ground or haning is supported.
Q3. Do you have any MOQ limit for led screen order?
A: Low MOQ, modules or complete screen order are all welcome.
Q4. What's the shipping method?
A: Air freight, sea and train transport according to different
region.
Q5. What's the payment method?
A: Mostly we accpet telegraphic transfer, 50% before production and
50% balance before shipment.
Q6. How do you control the production quality?
A: We manage quality starting from incoming material, all leds, ICs
and PSU are pre-inspected then go to the production line.
The modules and complete screen will have at least 72 hours aging
test, to make sure stable quality and performance.
Q7: How does warranty work?
A: We provide 1-3 years warranty for different product. Free Repair
or Exchange of Defective Parts with One way Shipping
