Ghost Series Indoor P3.91mm Stage Rental LED Display Front Magnetic
Service 3840Hz Refresh Rate
Feature Of Indoor Giant Series Rental LED Video Wall
Many people do not know that the purpose and function of stage
rental displays are different. Compared with traditional LED
displays, they need to be configured. The next LCF will use the
difference between the LED stage rental screen and the traditional
display example.
1. Different models selected
The stage rental screen has high requirements for stage display, so
the requirements for screen playback effect should be clearer.
Therefore, the general indoor environment adopts the
high-definition stage display of P3P4 model, and the small pitch
P2.5P2 is used in poor conditions P7P6 and other models are used
outdoors. For traditional indoor and outdoor displays, due to long
viewing distance or low display requirements, P6P5 is usually used
indoors, while P10 is most often used outdoors, followed by P16.
The interior is a surface sticker. Plug in lighting is usually used
outdoors, but sometimes the current surface mounted products are
used in the stage rental screen market, and a variety of box type
products are introduced, including all major models in the market.
P3P4P4.8P6, etc
2. How to install
Many people in the industry know that stage rental screens are easy
to remove and install. For example, at the end of a concert, you
can break up the concert and recreate it at another stage. The
conventional indoor LED display is usually a fixed installation
method, which is not easy to move after the fixed installation
position. Therefore, it would be impossible to rebuild in other
places after disassembly.
3. Box difference
Generally, traditional outdoor LED displays are waterproof and
heavy in structure. The interior is also a simple box, which is
used for LED stage rental display. It is usually made of
die-casting aluminum box, with light structure, high stability and
more convenient use. The most important thing is to install at any
time. Removable, suitable for concerts, stage and other major
performances. The above three points are the biggest differences
between the existing display and the screen leased at the current
stage. There are also other differences in the quotation, size and
configuration of the environment.
Quick detail Of Indoor Rental LED Screen
1, Pixel Pitch: 2.6mm. 2.9mm, 3.91mm
2, Quality and High Contrast SMD LEDs, Wide viewing angle: 140°/
140°.
3, Greyscale: 16bits, 22bits with NOVA Star A8S
4, Cabinet size: 500x500mm Die Cast Aluminum
5, Recommended Viewing Distance: 2-4m.
6, Cabinet Material: Die Cast Aluminum Cabinet, 7.5kg Weight
7, Refresh Rate: 3840-7680Hz
8, Ingress Rate: IP43 Indoor, IP68 Outdoor
9,Quality Certificate:CE, RoHS,FCC, ETL
10,Brightness:>1000cd/sqm
11, Curve Installation: Yes, Concave and Convex Available
12, Corner Protector: Yes, Semi-auto Corner Protector
Specification Of Indoor Rental LED Screen
| XT1.95 | XT 2.6 | XT 2.9 | XT 3.91 |
| Pixel Pitch | 1.953mm | 2.604mm | 2.97mm | 3.91mm |
| Pixel Configuration | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Pixel Density | 262,144 pixels/m2 | 147,456 pixels/m2 | 112,986 pixels/m2 | 65,536 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 | 500 x 500 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 | 2 x 2 | 2 x 2 | 2 x 2 |
| Module Resolution | 128x128 | 96 x 96 | 84 x 84 | 64 x 64 |
| Cabinet Resolution | 256x256 | 192 x 192 | 168 x 168 | 128 x 128 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 7.5kg | 7.5kg | 7.5kg | 7.5kg |
| Digital Processing | 16bit | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm | 200 W /Sqm | 200 W /panel | 200 W /panel |
| Max Power Consumption | 650 W /Sqm | 650 W /Sqm | 650 W /panel | 650 W /panel |
| Brightness | >1,000 nits | >1,000 nits | >1,000 nits | >1,000 nits |
| Refresh Rate | >3,840 Hz | >3,840 -7680Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front | Front |
| IP Rating (Front/Rear) | IP 43 | IP 43 | IP 43 | IP 43 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/32 Scan | 1/32 Scan | 1/21 Scan | 1/16 Scan |
Description Of Indoor Rental LED Screen
TBC LED XT Series indoor rental led screen include P1.95mm, P2.6mm,
P2.9mm, 3.91mm. Features are:
1, Curve Application via Rotary Lock
2, Flash Function: Calibration Data Saved and Used Automatically
3, Front and Rear Maintenance via Magnets
4, Independent Power Box
5, Poster Function, Easily switched to a LED Poster
Our Services
1. 10 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
FAQ
Q1. How does the semi auto corner protector work?
A: Gently push the button, the corner protector will release and
cover the corner area.
Q2. What installation options do we have?
A: Either stacking on ground or haning is supported.
Q3. Do you have any MOQ limit for led screen order?
A: Low MOQ, modules or complete screen order are all welcome.
Q4. What's the shipping method?
A: Air freight, sea and train transport according to different
region.
Q5. What's the payment method?
A: Mostly we accpet telegraphic transfer, 50% before production and
50% balance before shipment.
Q6. How do you control the production quality?
A: We manage quality starting from incoming material, all leds, ICs
and PSU are pre-inspected then go to the production line.
The modules and complete screen will have at least 72 hours aging
test, to make sure stable quality and performance.
Q7: How does warranty work?
A: We provide 1-3 years warranty for different product. Free Repair
or Exchange of Defective Parts with One way Shipping
