TBC Outdoor SMD LED Display P8: Redefining Outdoor Visual
Communication with Front - Open Design
TBC Outdoor SMD LED Display Quick Details:
- Pixel Pitch: 8mm, ensuring a balance between cost - effectiveness
and visual clarity for large - scale outdoor applications.
- SMD technology, offering an impressively Wide viewing angle of
160°/ 160°. This means that viewers from various positions can
clearly see the content, whether it's from the side or directly in
front.
- IP rating: front: IP65/ rear: IP54. The high - grade front - end
waterproof and dust - proof capabilities make it suitable for the
harshest outdoor environments, while the rear - end protection also
ensures the internal components are safeguarded.
- RGB full color, with a refresh rate of 2,000:1 and a high contrast
ratio of 4,000:1. These features result in vivid, sharp, and eye -
catching visuals, making every advertisement or media broadcast
stand out.
- Single face, front open, and customized cabinet. The front - open
design is a game - changer, especially for wall - mounted
installations where space for rear access might be limited.
- 3 - year warranty, providing customers with peace of mind and long
- term reliability.
TBC Outdoor SMD LED Display Description:
TBC is at the forefront of LED display technology, and our SMD led
displays are a testament to our innovation. Our product line
encompasses a wide range of outdoor led billboards and indoor led
video walls, suitable for both fixed installation and rental
purposes. The pixel pitch options are diverse, ranging from 1.25mm
for high - definition indoor applications to 16mm for large - scale
outdoor displays. The TBC Outdoor SMD LED Display P8, with its
unique front - open design, is specifically engineered to meet the
demands of modern outdoor advertising and media dissemination.
TBC Outdoor SMD LED Display Application:
The TBC Outdoor SMD LED Display P8 is a versatile solution with a
wide range of applications. It is extensively used for commercial
advertising, becoming the focal point of any shopping mall,
building, or storefront. In media broadcasting, it serves as a
reliable platform for delivering real - time news, sports events,
and entertainment content. For stage backgrounds, it adds a dynamic
visual element to concerts, theater performances, and other live
events. Wall - mounted installations in schools, airports, and
stations provide important information and announcements. Whether
it's pole - mounted for traffic - related information or hang -
mounted in stadiums, the TBC Outdoor SMD LED Display P8 is up to
the task.
TBC Outdoor SMD LED Display Features and Advantages:
- Build - in intelligent sensor: This advanced feature allows the
display to adjust its brightness according to the ambient
environment. It also has the ability to detect and display the
environment's temperature and humidity. This not only saves energy
but also ensures optimal visual performance in all lighting
conditions.
- Good heat dissipation with fan cooling system: Outdoor environments
can be harsh, and high temperatures can affect the performance of
the LED display. The fan cooling system in the TBC Outdoor SMD LED
Display P8 effectively dissipates heat, ensuring the longevity and
stable operation of the display.
- IP65 high - performance waterproof and dust resistance: The front -
end IP65 rating means that the display is protected against water
jets and dust ingress. This makes it suitable for use in rain,
snow, and dusty conditions, ensuring that the display remains
operational throughout the year.
- Front - open design: The front - open design is a major advantage,
especially for wall - mounted setups. It enables front - side
service, which is extremely convenient for maintenance. This design
also saves valuable maintenance space, making it ideal for
installations where rear access is restricted.
- SMD LEDs ensure large viewing angle: With SMD LEDs, the viewing
angle of the TBC Outdoor SMD LED Display P8 is up to 160°
horizontally and 160° vertically. This ensures that a large number
of people can view the content clearly, maximizing the reach of
your message.
Parameters:
| Parameter | Unit | Value |
| Brightness | nits | 6000 |
| Color temperature | deg.k | 3200 ~ 9300 |
| Viewing angle - Horizontal | deg. | 160(+80/-80) |
| Viewing angle - Vertical | deg. | 160(+80/-80) |
| Cabinet weight | kg | 61 |
| Cabinet width | mm | 1024 |
| Cabinet height | mm | 1024 |
| Cabinet depth | mm | 150 |
| Cabinet area | sq. m. | 1.05 |
| Cabinet material | | Cold Steel |
| Aspect ratio | | 1:1 |
| Ingress protection (Front/Rear) | IP | IP65/IP54 |
| Operating temperature range | deg. C | - 20 to 50 |
| Operating humidity range | HR | 10％ to 90％ |
| Pixel type and configuration | R/G/B | SMD 3in1 |
| Pixel pitch | mm | 8 |
| Pixel matrix per cabinet | | 128x128 |
| Pixels per cabinet | | 16384 |
| Lines per meter | | 125 |
| Pixels per sq. meter | | 15625 |
| LEDs per sq. meter | | 15625 |
| Recommended minimum viewing distance | m | 8 |
| Colours | | 281trillion |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Digital processing | bit | 16 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 1920 |
| Input voltage | VAC | 110/240 |
| Input power frequency | Hertz | 50/60 |
| Input power (max/avg) | Watts per sq.m | 1330/460 |
| MTBF | Hours | ≥10000 |
| Lifetime (50%Brightness) | Hours | ≥100000 |
| Module brightness uniformity | | ＜5％ |
| Blind spot rate | | ＜0.0001 |
| Earth leakage current | mA | ＜2 |
| Red wavelength | nm | 623 |
| Green wavelength | nm | 525 |
| Blue wavelength | nm | 470 |
| Panel input format (with video processor) | | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV |
| Data interconnection | | CAT6 cable/Fiber |
| Operating system | | Windows(XP/Vista/7/8/10) |
| Control distance | | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. |
