    TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals

    Ask Lasest Price
    Brand Name : TBC
    Model Number : E8-A
    Certification : CE-EMC, CE-LVD, RoHS, ETL, FCC
    Price : Negotiable
    Payment Terms : T/T, Western Union, PayPal
    Supply Ability : 10,000sqm/month
    Delivery Time : 15-25days
    • Product Details
    • Company Profile

    TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals

    Discover the TBC Outdoor SMD LED Display P8: A Marvel of Outdoor Display Technology


    TBC Outdoor SMD LED Display P8: Revolutionizing Outdoor Visuals with Advanced Features


    Outdoor LED screen Quick Details:
    1. Pixel Pitch: 8mm, offering a cost - effective yet high - quality visual solution for outdoor applications.
    2. SMD technology, delivering a Wide viewing angle of 160°/ 160°. This wide viewing angle ensures that the display can be seen clearly from different positions, making it suitable for crowded areas.
    3. IP rating: front: IP65/ rear: IP54. The high - level waterproof and dust - proof ratings protect the display from the elements, ensuring its long - term performance.
    4. RGB full color, refresh rate: 2,000:1, high contrast: 4,000:1. These features result in vivid and sharp images, making the content more appealing and engaging.
    5. Single face, front open, customized cabinet. The front - open design simplifies maintenance, and the customized cabinet can be designed to fit any installation space.
    6. 3 - year warranty, providing customers with long - term support and assurance.
    Outdoor LED screen Description:
    TBC offers a diverse range of SMD led displays, including both outdoor and indoor models. Our outdoor led billboards are designed to withstand the harshest outdoor conditions, while our indoor led video walls are perfect for creating immersive visual experiences. The pixel pitch options range from ultra - high - definition small - pitch displays to larger - pitch displays suitable for outdoor use. The TBC Outdoor SMD LED Display P8 is a prime example of our commitment to providing high - quality outdoor display solutions.
    Outdoor LED screen Application:
    The TBC Outdoor SMD LED Display P8 has a wide range of applications. In the advertising industry, it can be used to create eye - catching billboards that attract the attention of passers - by. In the media industry, it can be used for live event broadcasts, such as concerts and sports games. In educational institutions, it can be used for announcements and information dissemination. In entertainment venues like cinemas and concert halls, it can be used to display trailers, event schedules, and other important information.
    Outdoor LED screen Features and Advantages:
    1. Build - in intelligent sensor: The intelligent sensor in the TBC Outdoor SMD LED Display P8 adjusts the brightness according to the ambient light. It also monitors the temperature and humidity, ensuring that the display operates optimally in all conditions.
    2. Good heat dissipation with fan cooling system: Outdoor displays are exposed to high temperatures, and the fan cooling system in the TBC Outdoor SMD LED Display P8 helps to dissipate heat effectively. This ensures the longevity and stability of the display.
    3. IP65 high - performance waterproof and dust resistance: The front - end IP65 rating makes the display highly resistant to water and dust. This means that it can be installed in areas with heavy rain, snow, or dust without any issues.
    4. Front - open design: The front - open design of the TBC Outdoor SMD LED Display P8 allows for easy maintenance. This is a significant advantage, especially for wall - mounted installations where rear access may be limited.
    5. SMD LEDs ensure large viewing angle: The SMD LEDs in the TBC Outdoor SMD LED Display P8 provide a large viewing angle, ensuring that the content can be seen clearly from different directions.

    TBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor VisualsTBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor VisualsTBC P8 Outdoor SMD LED Display Front Service Maintenance and RGB 3in1 LEDs for Exceptional Outdoor Visuals


    Parameters:
    ParameterUnitValue
    Brightnessnits6000
    Color temperaturedeg.k3200 ~ 9300
    Viewing angle - Horizontaldeg.160(+80/-80)
    Viewing angle - Verticaldeg.160(+80/-80)
    Cabinet weightkg61
    Cabinet widthmm1024
    Cabinet heightmm1024
    Cabinet depthmm150
    Cabinet areasq. m.1.05
    Cabinet material Cold Steel
    Aspect ratio 1:1
    Ingress protection (Front/Rear)IPIP65/IP54
    Operating temperature rangedeg. C- 20 to 50
    Operating humidity rangeHR10% to 90%
    Pixel type and configurationR/G/BSMD 3in1
    Pixel pitchmm8
    Pixel matrix per cabinet 128x128
    Pixels per cabinet 16384
    Lines per meter 125
    Pixels per sq. meter 15625
    LEDs per sq. meter 15625
    Recommended minimum viewing distancem8
    Colours 281trillion
    Gray scaleLevels65536 levels per colour
    Brightness controlLevels100
    Digital processingbit16
    Frame rateHertz60
    Display refresh rateHertz1920
    Input voltageVAC110/240
    Input power frequencyHertz50/60
    Input power (max/avg)Watts per sq.m1330/460
    MTBFHours≥10000
    Lifetime (50%Brightness)Hours≥100000
    Module brightness uniformity <5%
    Blind spot rate <0.0001
    Earth leakage currentmA<2
    Red wavelengthnm623
    Green wavelengthnm525
    Blue wavelengthnm470
    Panel input format (with video processor) VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV
    Data interconnection CAT6 cable/Fiber
    Operating system Windows(XP/Vista/7/8/10)
    Control distance Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers.
