    Energy-Saving P3.125 Outdoor LED Billboard with Durable Aluminum Cabinet and SMD1415 LEDs for High-Performance Advertising

    Ask Lasest Price
    Brand Name : TBC LED
    Model Number : P3.125
    Certification : FCC, CE, ROHS
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 1000 sqm per month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    Energy-Saving P3.125 Outdoor LED Billboard with Durable Aluminum Cabinet and SMD1415 LEDs for High-Performance Advertising

    Energy-Saving P3.125 Outdoor LED Billboard with Durable Aluminum Cabinet and SMD1415 LEDs for High-Performance Advertising


    1. P3.125 Outdoor LED Display Technical Specifications:

    Product Parameters

    ModeEnergy-saving outdoor LED billboard
    LEDs1R1G1B
    LED typeSMD1415
    Pixel pitch3.125mm
    Module sizeW400×H300mm
    Panel Size800×900×98mm
    Panel resolution256×288 dots
    Resolution102,400dots/㎡
    Brightness5000nit
    Weight17.5KG/㎡
    Max consumption780W/㎡
    Adv consumption200-300W/㎡
    Viewing angleH140°/V160°
    Protection levelIP65
    Thickness98mm

    Heat dissipation

    Convective heat dissipation
    Wind dissipaionLevel 12
    Power supplyPower supply with PFC
    InstallationFast install
    Fire safety10S/unit
    Fire resistanceFull VO grade
    ServiceFront,Back
    Control modesteady state
    Color temperature1000-18500K
    Refresh rate>3840Hz
    Operating temperature/humidity range-20℃ to 60℃/10%-85%
    Storage temperature/humidity range-20℃ to 60℃/10%-85%
    Life time≥100,000 hours
    Input voltageAC110-220V
    Grey grade16bit
    Seismic capability10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
    CertificatesCCC/CE/RoHs/FCC/CB/TUV/IEC
    Warranty2 Years
    2. P3.125 Outdoor Energy-Efficient LED Display – Quick Specifications:

    1. Pixel Pitch: 3.125mm
    2. LED lamp:Nationstar SMD1415
    3. Cabinet size: 800x900 Aluminum Cabinet

    4. Cabinet thickness: 98mm
    5.
    Best viewing distance(m): 4-150m.

    6. Cabinet Material: Aluminum, 17.5kg per panel
    7. Maintenance: Front and rear

    8. Refresh Rate: >3840Hz

    9. Contrast ratio: 10000:1

    10. Ingress Rate: IP65,durable for outdoor use;
    11. Greyscale: 16bits;

    12. Quality Certificate:CE, RoHS,FCC,etc.
    13. Lifespan:100,000hours

    14. Warranty: 2years


    3. P3.25 Outdoor LED Billboard – Product Features (Energy-Saving Design):

    1. Ultra-Fine Pixel Pitch Options (P3.125/P4.16/P5/P6.25/P8.33/P10)
    Our cutting-edge LED displays offer a comprehensive range of pixel pitches from ultra-high-definition P3.125 to versatile P10, ensuring perfect solutions for any viewing distance requirement.


    2. Modular Cabinet Design with Dual Size Options
    The 800×900mm (17.5kg) and 800×1200mm (22.5kg) cabinet sizes provide flexible configuration possibilities for diverse installation scenarios.



    3. Industry-Leading 5000-6500nit Brightness
    Our displays maintain perfect visibility even under direct sunlight while conserving energy during nighttime operation. The advanced 16bit grayscale processing delivers true-to-life color reproduction that outperforms conventional LED screens by 30% in contrast ratio.



    Our Services


    1. 15 Years professional led display manufacturer

    2. Short delivery time: 5-15 working days, adjustable according to customer request
    3. Wholesale price

    4. OEM and ODM service
    5. Customizable product upon request


    FAQ


    Q1. How does the service work?

    A: We have experienced Engineers who worked in the industry for 15 years and able to communicate with fluent English. They can remotely provide technical support via video conference or teamviewer or go to the site for the guidance.

    Q2. What installation options do we have?

    A: Wall mounting with metal structures.

    Q3. Do you have any MOQ limit for led screen order?

    A: Low MOQ, modules or complete screen order are all welcome.

    Q4. What's the shipping method?

    A: Air freight, sea and train transport according to different region.

    Q5. What's the payment method?

    A: Mostly we accpet telegraphic transfer, 50% before production and 50% balance before shipment.

    Q6. How do you control the production quality?

    A: We manage quality starting from incoming material, all leds, ICs and PSU are pre-inspected then go to the production line.

    The modules and complete screen will have at least 72 hours aging test, to make sure stable quality and performance.

    Q7: How does warranty work?

    A: We provide 1-3 years warranty for different product. Free Repair or Exchange of Defective Parts with One way Shipping
