Outdoor P10mm Led Media Video Wall
Application:
LED Display Application:
(1) Building Curtain Wall
The installation of curtain walls on urban buildings is primarily
concentrated in the prosperous areas of the city. This presents a
significant potential market for outdoor media advertising, as
these buildings, such as city landmarks, municipal buildings,
airports, automobile 4S stores, hotels, banks, and chain stores
with commercial value can be utilized for advertising purposes.
(2) Municipal Engineering
LED displays can be strategically placed at busy street
intersections, large parks, major commercial centers, subways,
highways and other high-traffic municipal areas to disseminate
information and publicize important announcements from the
municipal department.
(3) Sports Events
The application of LED displays in sports venues is crucial for
providing real-time game broadcasts and replaying exciting moments
for better audience engagement. Additionally, slow motion replays
can assist referees in making accurate decisions to reduce disputes
and ensure fair play. Furthermore, LED displays are also used for
athlete introductions, displaying competition results and
broadcasting commercial advertisements. The versatility of LED
full-color display screens makes them indispensable in various
events such as the Olympic Games and World Cup. As modern sports
venues continue to evolve with the development of the sports
industry,the demand for LED full-color displays remains on the rise
across football fields,basketball stadiums,and track-and-field
arenas.
Features and Advantages:
1. The SMD (3-in-1) LED package provides wider viewing angles and
extremely close viewing distances.
2. Advanced video processing produces crystal-clear, detailed
images with smooth motion reproductions.
3. High brightness,waterproof IP65, dust-proof, UV-proof,
noise-free, endure high-temperature, corrosion resisting. Work
stable in 365 days 24 hours at any weather.
4. Low power consumption, environmental protection and energy
saving.
5. Image feeds delivered in both standard and high-definition
formats.
6. Full-depth image calibration in the factory and in the field
provides for a uniform display picture.
7. Integrates seamlessly with a variety of other video products.
Parameters
| Brightness | nits | 7000 |
| Color temperature | deg.k | 3200 ~ 9300 |
| Viewing angle - Horizontal | deg. | 160(+80/-80) |
| Viewing angle - Vertical | deg. | 160(+80/-80) |
| Cabinet weight | kg | 43 |
| Cabinet width | mm | 960 |
| Cabinet height | mm | 960 |
| Cabinet depth | mm | 120 |
| Cabinet area | sq. m. | 0.11 |
| Cabinet material | | Cold Steel |
| Aspect ratio | | 1:1 |
| Ingress protection (Front/Rear) | IP | IP65 |
| Operating temperature range | deg. C | - 20 to 50 |
| Operating humidity range | HR | 10％ to 90％ |
| Pixel type and configuration | R/G/B | SMD 3in1 |
| Pixel pitch | mm | 10 |
| Pixel matrix per cabinet | | 96x96 |
| Pixels per cabinet | | 9216 |
| Lines per meter | | 250 |
| Pixels per sq. meter | | 10000 |
| LEDs per sq. meter | | 10000 |
| Recommended minimum viewing distance | m | 10 |
| Colours | | 281trillion |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Digital processing | bit | 16 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 3840 |
| Input voltage | VAC | 110/240 |
| Input power frequency | Hertz | 50/60 |
| Input power (max/avg) | Watts per sq.m | 970/330 |
| MTBF | Hours | ≥10000 |
| Lifetime (50%Brightness) | Hours | ≥100000 |
| Module brightness uniformity | | ＜5％ |
| Blind spot rate | | ＜0.0001 |
| Earth leakage current | mA | ＜2 |
| Red wavelength | nm | 623 |
| Green wavelength | nm | 525 |
| Blue wavelength | nm | 470 |
| Panel input format (with video processor) | | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV |
| Data interconnection | | CAT6 cable/Fiber |
| Operating system | | Windows(XP/Vista/7/8/10) |
| Control distance | | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. |
