500x1000mm P2.9mm Indoor Stage Rental LED Display With 3840Hz
Refresh Rate
Indoor Rental LED Display 500x1000mm P2.9mm Die Cast Aluminum With
3840Hz Refresh Rate
Indoor P2.9mm 500x1000mm Stage Rental LED Display 3840Hz Refresh
Rate
Introduce:
The Rock Series is a 500X1000mm-based die-casting aluminum rental
LED display screen. With the 500X500 box as the primary mold, it
can be effortlessly assembled to create stage effect sizes such as
10X9, 8X7, 6X5, 4X3, 2X1 meters. It is capable of splicing both
radian and right angles and can be used as a stadium screen.
This series utilizes Taiwan's Accumulation IC solution. It features
high brush frequency, high gray scale, and high contrast. The light
die-cast aluminum material ensures that installation and removal
are not only simple but also time-saving. The multiple functions of
this series have made it widely recognized and appreciated by
customers in the market.
Addvantages:
- Arc splicing is a notable feature. The box body has a corner that
allows for radian splicing, perfectly suiting stage applications.
This gives the flexibility to create diverse and visually appealing
curved displays for the stage.
- The lightweight quick lock catch is a significant advantage. It
simplifies the connection process, making it quick and effortless
while maintaining a secure hold.
- The lightweight nature greatly facilitates transportation and
installation. It makes handling and setup much easier, especially
in situations where portability and rapid installation are key.
- The use of Taiwan MBI IC leads to a superb display. The colors are
brilliant, and the image stability is commendable, offering a
top-notch visual experience.
- The high refresh rate, which is higher than 1920HZ, eliminates any
smearing. This ensures sharp and clear visuals, especially for
content that demands high fluidity.
- The combination of high contrast, high brush, and high gray levels
significantly improves image quality, providing enhanced clarity
and sharpness.
- The inclusion of high-quality black lamp beads ensures stable
performance and a low blind spot rate. This results in a
consistently clear and reliable display.
Quick Details:
- Pixel pitch choices include 2.6mm, 2.9mm, and 3.91mm.
- This product incorporates quality and high-contrast SMD LEDs,
offering a wide viewing angle of 140° in both horizontal and
vertical directions.
- The greyscale reaches 16bits, supported by the NOVA Star MRV328.
- The cabinet measures 500x1000mm and is fabricated from die-cast
aluminum.
- It is suggested that the optimal viewing distance lies between 2
and 4 meters.
- The cabinet material is die-cast aluminum, and it weighs 7.5
kilograms.
- The refresh rate varies from 1920 to 3840Hz.
- The ingress protection rate is IP43 for indoor applications.
- It has obtained quality certifications like CE, RoHS, FCC, and ETL.
- The brightness is greater than 1000cd/sqm.
- Curve installation is feasible, with both concave and convex
options accessible.
- Corner protectors are available for added protection.
Specification:
| XT1.95 | XT 2.6 | XT 2.9 | XT 3.91 |
| Pixel Pitch | 1.953mm | 2.604mm | 2.97mm | 3.91mm |
| Pixel Configuration | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Pixel Density | 262,144 pixels/m2 | 147,456 pixels/m2 | 112,986 pixels/m2 | 65,536 pixels/m2 |
| Module Dimensions(W x H) (mm) | 250 x 250 | 250 x 250 | 250 x 250 | 250 x 250 |
| Panel Dimensions (mm) | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 | 500 x 1000 x 80 |
| Modules Per Cabinet (W x H) | 2 x 2 | 2 x 2 | 2 x 2 | 2 x 2 |
| Module Resolution | 128x128 | 96 x 96 | 84 x 84 | 64 x 64 |
| Cabinet Resolution | 256x256 | 192 x 192 | 168 x 168 | 128 x 128 |
| Panel Material | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum | Die Cast Aluminum |
| Weight per Cabinet | 15kg | 15kg | 15kg | 15kg |
| Digital Processing | 16bit | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 | 5,000 : 1 |
| Average Power Consumption | 200 W /Sqm | 200 W /Sqm | 200 W /panel | 200 W /panel |
| Max Power Consumption | 650 W /Sqm | 650 W /Sqm | 650 W /panel | 650 W /panel |
| Brightness | >1,000 nits | >1,000 nits | >1,000 nits | >1,000 nits |
| Refresh Rate | >3,840 Hz | >3,840 -7680Hz | >3,840 Hz | >3,840 Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front | Front |
| IP Rating (Front/Rear) | IP 43 | IP 43 | IP 43 | IP 43 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Scan Method | 1/32 Scan | 1/32 Scan | 1/21 Scan | 1/16 Scan |
Description:
The TBC LED Rock Series indoor rental led screen offers a range of
pixel pitches including P1.95mm, P2.6mm, P2.9mm, and 3.91mm.
- It is suitable for a wide variety of rental events and fixed
installations. This flexibility makes it a versatile choice for
different occasions and settings.
- The diodes of good quality guarantee high brightness and high
contrast, providing clear and vivid visual effects.
- Maintenance can be carried out from both the front and the rear via
magnets, which simplifies the maintenance process and saves time
and effort.
- The refresh rate is an impressive 3840Hz and can be adjusted
according to specific requirements, ensuring smooth and seamless
image display.
- The 500x500mm die cast aluminum cabinet is not only lightweight but
also sleek, facilitating transportation and installation.
Our Services
- We are a professional led display manufacturer with 10 years of
experience.
- We offer a short delivery time, typically ranging from 5 to 15
working days. This can be adjusted based on your specific requests.
- You'll enjoy wholesale prices for our products.
- We provide OEM and ODM services to meet your unique requirements.
- Our products are customizable as per your requests.
Our Services
- With a decade of expertise, we are a renowned professional led
display manufacturer.
- Our delivery time is short, usually within 5 to 15 working days.
However, it can be tailored to your demands.
- Avail of our wholesale prices for cost-effective solutions.
- We offer OEM and ODM services to customize the products precisely
as you envision.
- You can request customizations for the product to meet your
specific needs.
FAQ
Q1. How does the semi-auto corner protector operate?
A: Just give the button a gentle push, and the corner protector
will be released, providing protection to the corner area.
Q2. What installation alternatives do we provide?
A: We offer two main options: stacking on the ground or hanging,
allowing you to choose the one that best suits your situation.
Q3. Is there a minimum order quantity (MOQ) limit for led screen
orders?
A: We have a relatively low MOQ. Both module and complete screen
orders are highly appreciated and accepted.
Q4. What shipping methods can you choose from?
A: Based on different regions, we offer air freight, sea
transportation, and train transport to ensure timely and safe
delivery.
Q5. What are the accepted payment methods?
A: Generally, we accept telegraphic transfer. The payment structure
is 50% before commencing production and 50% of the balance before
shipment.
Q6. How is the production quality controlled?
A: Quality management begins with the inspection of incoming
materials. All LEDs, ICs, and PSUs are pre-checked before entering
the production line. Additionally, the modules and complete screens
undergo at least 72 hours of aging tests to ensure consistent
quality and reliable performance.
Q7: How is the warranty implemented?
A: We provide warranties ranging from 1 to 3 years for different
products. In case of defects, we offer free repair or exchange of
faulty parts along with one-way shipping.
