Outdoor Rental Transparent LED Display P3.91-7.81mm Hight Brightness SMD1921 3840Hz
Quick details:
1. Pixel Pitch: 3.91-7.81mm
2. SMD1921, high brightness 6000nits and high refresh rate 3840Hz
3. Greyscale: 16bits
4. Cabinet size: 1000×500mm
5. Recommended Viewing Distance: 3-8m.
6. Cabinet Material: Aluminum Cabinet, 7.8kg/㎡ Weight
7. Quality Certificate:CE, RoHS,FCC, ETL
8.Quick Installation: Yes, can be hung from the ceiling or mount to
the wall
Specification
Product Unit Parameters Parameters |
| Mode | P3.91-7.81mm |
| LEDs | 1R1G1B |
| LED type | SMD1921 |
| Pixel pitch | 3.91-7.81mm |
| Unit size | W1000×H500mm(W1000×H1000mm) |
| Unit resolution | 256×64 dots |
| Resolution | 32,768dots/㎡ |
| Unit direction | Vertical Horizontal |
| Brightness | 6000nit |
| Weight | 7.8KG/㎡ |
| Max consumption | ≤800W/㎡ |
| Adv consumption | ≤260W/㎡ |
| Viewing angle | H120°/V120° |
| Protection level | IP65 |
| Thickness | 82mm |
Heat dissipation | Convective heat dissipation |
| Power supply | Power supply with PFC |
| Installation | Fast install |
| Service | Front&Back |
| Control mode | steady state |
| Color temperature | 3200-9300K |
| Refresh rate | 3840Hz |
| Working temperature | -40℃ to 70℃ |
| Storage temperature | -55℃ to 120℃ |
| Life time | ≥100,000 hours |
| Input voltage | AC110-220V, 50~60Hz |
| Grey grade | 16bit |
Features:
1. Lightweight and Slim Design: Features a slim frame design with a thickness of only 65mm and a
weight of 16kg per square meter.
2. Outdoor Waterproof Design: Rated IP65. Constructed from die-cast aluminum, offering excellent
weather resistance, moisture-proofing, corrosion resistance,
waterproofing, and strong wind resistance.
3. Easy Assembly and Maintenance: Convenient for rental applications. The modular design and
integrated power box enable quick maintenance. Equipped with
handles and quick-lock mechanisms to save installation time.
4. Supports ±10° Curved Splicing: Capable of splicing into various shapes to meet diverse
requirements.
5. Customizable Cabinet Dimensions: Cabinet sizes can be tailored according to project specifications
to fully meet your product needs.
Our Services
1. 10 Years professional led display manufacturer
2. Short delivery time: 5-15 working days, adjustable according to
customer request
3. Wholesale price
4. OEM and ODM service
5. Customizable product upon request
FAQ
Q1. How does the service work?
A: We have experienced Engineers who worked in the industry for 15
years and able to communicate with fluent English. They can
remotely provide technical support via video conference or
teamviewer or go to the site for the guidance.
Q2. What installation options do we have?
A: Wall mounting with metal structures or hanging from ceiling
Q3. Do you have any MOQ limit for led screen orders?
A: Low MOQ, modules or complete screen orders are all welcome.
Q4. What's the shipping method?
A: Air freight, sea and train transport according to different
regions.
Q5. What's the payment method?
A: Mostly we accept telegraphic transfer, 50% before production and
50% balance before shipment.
Q6. How do you control the production quality?
A: We manage quality starting from incoming material, all LEDs, ICs
and PSU are pre-inspected then go to the production line.
The modules and complete screen will have at least 72 hours aging
test, to make sure of stable quality and performance.
Q7: How does warranty work?
A: We provide 1-3 years warranty for different products. Free
Repair or Exchange of Defective Parts with One-way Shipping
